28 | minnkota.johnsonoutdoors.com ©2023 Johnson Outdoors Marine Electronics, Inc.
KEEL OFFSET
c. Press the Menu button on the Wireless Remote.
d. Use the Speed Up
or Speed Down
button to find the Motor Settings menu. Use the
Steer Right
button to select Motor Settings.
e. In the Motor Settings Menu, use the Speed Up
or Speed Down button to find
Setup/Calibration.
f. In the Setup/Calibration menu, use the Speed Up
or Speed Down button to find Keel
Mount Oset. Use the Steer Right
button to select
Keel Mount Oset.
2
2e2d
2f
g. Review all safety warnings. Use the Steer Right
button to select Start and begin the process.
h. Use the Steer Left
or Steer Right button to point
the motor forward and parallel to the keel.
i. When satisfied with the placement of the trolling
motor, use the Speed Up
or Speed Down
button to scroll to Set. Use the Steer Right
button to select Set. The degree of oset is displayed
at the bottom of the Dashboard.
3
3h
3i
3g
To Next Page
