66 | minnkota.johnsonoutdoors.com ©2023 Johnson Outdoors Marine Electronics, Inc.
PARTS DIAGRAM & PARTS LIST
Control Head Parts List
Assembly Part # Description Notes Quantity
A 2994183 MTR KIT, 4.0 BL SW-BK WR *RT INSTINCT QUEST* *SALTWATER BLACK* 1
B 2994194 MTR KIT, 4.0 BL SW WR *RT INSTINCT QUEST* *SALTWATER WHITE* 1
C 2770248 CTRL BOX COVER QUEST SW WHT
*COVER & DECALS ONLY* *RT INSTINCT QUEST*
*SALTWATER WHITE*
1
D 2770249 CTRL BOX COVER QUEST SW BLK
*COVER & DECALS ONLY* *RT INSTINCT QUEST*
*SALTWATER BLACK*
1
E 2992371 STABILIZER, BWMT ES TM ASM *72"* *87"* *100"* 1
F 411690-1 TROLLING MOTOR REMOTE 1
G 2994955 BAG, ASM MKA-60 STABILIZER *72"* *87"* *100"* 1
Item Part # Description Notes Quantity
2
2200221 CONTROL BOX COVER, WHITE *SALTWATER WHITE* 1
2200220 CONTROL BOX COVER, BLACK *SALTWATER BLACK* 1
4
2395561 DECAL,PUSH BTN, INST, WHT *SALTWATER WHITE* 1
2395595 DECAL, PUSH BTN, INSTINCT *SALTWATER BLACK* 1
6 2205543 DECAL, CTRL BOX MK RIGHT SW 1
8 2205548 DECAL, CTRL BOX MK LEFT SW 1
10 2203441 SCREW-#6 X 1/2" THRD FORM,SSTL 3
12 2206302 TIE WRAP,SCREW MOUNT 6.3" 1
14 2206710 PLUG, RUBBER, DI/SI 1
16 2205412 SHRINK TUBE-.75 ID X 2” 1
18 2372100 SCREW-#8-18 X 5/8 THD* (SS 4
20 2206301 TIE WRAP, LOW PROFILE 8" 1
22
2202521 CONTROL BOX BASE, ULTERRA SW *SALTWATER WHITE* 1
2202520 CONTROL BOX BASE, ULT,UTX, FW *SALTWATER BLACK* 1
24 2263406 SCREW-#10-24 X 2" S/S PPH 1
26 2333101 NUT-HEX #10-24 UNC-2B NYL SS 2
28 2390802 LANYARD w/CARARBINER IP RMT U2 1
30 490637- 4 CABLE, ETH, M12-M12, BRAID,30' 1
32 490380-1 CABLE, ETHERNET PIGTAIL-700 HD 1
34 2201530 COLLAR HALF, COIL CORD *72"* *87"* *100"* 2
36 2201531 COLLAR ARM, COIL CORD *72"* *87"* *100"* 1
38 2203424 SCREW-#10-12 x.75 PTH SS *72"* *87"* *100"* 2
40 2200860 CLAMP-BALL,COIL CORD SLDR *72"* *87"* *100"* 2
42 830-065 SCREW-#6-32 X 1/2" TORX PH SS *72"* *87"* *100"* 2
44 2323110 NUT-HEX, 6-32 NYLOK SS *72"* *87"* *100"* 2
46 2203460 SCREW-#8 X 0.75 PPH HI-LO SS *72"* *87"* *100"* 2
48 2375444 SPLICER, 6-10 AWG, TIN PLTD 2
50 2205413 SHRINK TUBE-3/4 X 2.25" 2
52 2205410 SHRINK TUBE-.472 ID X 4” 1
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
