PARTS DIAGRAM & PARTS LIST
Item Part # Description Notes Quantity
54 2383475 SCREW - #8-18 X 1 1/2 SELF DR SS *72"* *87"* *100"* 4
58 2201721 WASHER - #10 SAE.], SS 1
60 2203411 SCREW-#10-24,SHCS,SS, RIE 4606 1
62 2206721 PLUG-WIRE, ROUND *87"* *100"* 1
64 2202800 BLOCK-BELT 1
66 2200800 BELT-RACK, LOWER 1
68 2202335 PULLEY, BELY TOP 1
70 2202635 PIN-DOWEL, 1/4" OD SS 1
p
2207127 MANUAL, INSTINCT 1
p
2207128 MANUAL, INSTL GD, INSTINCT 1
p
2297165 MANUAL-DISCLAIMER,DWNLOAD INFO 1
p
2294950 INSTRUCTIONS,OBN & REMOTE PAIR 1
p
2397115 GUIDE-QUICK REFERENCE iP 4.0 1
p
2397110 MANUAL, iPILOT 4.0 1
p
2207130 BRUSHLESS QS SETUP GUIDE 1
p
2207126 QK REF GUIDE,ULT Q/INST Q 1
p
2395540 DECAL, COMPLIANCE, KIT 1.6, 3.0 1
p
2377179 INSTR. SHEET, MKA-60 STABILIZER *72"* *87"* *100"* 1
p
2206819 LABEL-CARTON "CAUTION HEAVY" 1
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
To Next Page
