72 | minnkota.johnsonoutdoors.com ©2023 Johnson Outdoors Marine Electronics, Inc.
PARTS DIAGRAM & PARTS LIST
Steering Housing Parts List
Assembly Part # Description Notes Quantity
Y 2996531 ASM, STEERING, SW, WHT *SALTWATER WHITE* 1
Z 2996532 ASM, STEERING, SW BLK *SALTWATER BLACK* 1
Item Part # Description Notes Quantity
170 2206401 PLATE, MOTOR MNT, STEERING 1
172 2204640 SEAL,ID 12MM, OD 20MM, T 5MM 1
174 2207012 MOTOR, 24 VDC, 1:130 GEARBOX 1
176 2204617 O-RING, 3/16 ID X 3/8 OD 4
178 2203414 SCREW-M5X.8X12,FLANGED BTN HD 4
180 2200602 STEERING CORD ASM 1
182 2204040 SENSOR,STEERING,ROTATIONAL,I/T 1
184 2374628 SEALING WASHER, RUBBER 4
186 2071714 WASHER-FLAT #6 S/S 4
188 2203441 SCREW-#6 X 1/2" THRD FORM,SSTL 4
190
2326568 HSG-BTM, STRING,SW,WHT *SALTWATER WHITE* 1
2206575 HSG-BTM, STEERING, SW, BLK *SALTWATER BLACK* 1
192 2204621 SEAL, STEERING HOUSING SPLIT 1
194 2202619 PIN-DOWEL, 3/16 X 1/2, SS 4
196 2382682 PIN-DOWEL, 1/4" X 5/8" SS 2
198 2206920 GASKET, MOTOR HOUSING,STEERING 1
200 2332101 SCREW-#8-32 X 1/2 (SS) 7
202 2992225 GEAR-STEER SENSOR,51T,w/MAGNET 1
204 2202214 GEAR-TRIM, 14T 1
206 2206572 COVER, STEER SENSOR GEARS 1
208 2203441 SCREW-#6 X 1/2" THRD FORM,SSTL 2
210 p 9950433 TIE WRAP-4" BLACK(#21041) 1
212 2202212 GEAR, 30 TOOTH,PINION,STEERING 1
214 2207302 BRG, 55 X 72 X 9MM, SSTL 1
216 2202000 OUTPUT TUBE, ANDIZED 1
218 p 2204606 O-RING,-139,NOM ID 2.25, 1
220 2207320 BUSHING, 55MM, JFM-5560-50 1
222 2207321 BUSHING,OUTPUT TUBE,TOP,INSTNC 1
224 2293001 RETAINING RING, 2 3/8" 1
226 2207911 HUB, STEERING STOP, ANODIZED 1
228 2201715 WASHER-THRUST, OUTPUT TUBE 1
230 2205910 GREASE CAP BEARING 1
232
2206563 HSG-TOP, STEERING,SW, WHT *SALTWATER WHITE* 1
2206559 HSG-TOP, STEERING, SW BLK *SALTWATER BLACK* 1
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
