minnkota.johnsonoutdoors.com | 73 ©2023 Johnson Outdoors Marine Electronics, Inc.
PARTS DIAGRAM & PARTS LIST
Item Part # Description Quantity
234 2207345 BUSHING, OUTPUT TUBE, LOWER 1
236 2207340 BUSHING, JFM-2023-11 1
238 2208640 VENT FILTER, STEERING HOUSING 1
240 2201941 MNT, SENSOR, LATCH QRP 1
242 2373440 SCREW-#4-24 X 1/4 PHCR SS TY B 2
244 2293403 SCREW-#6-32 X .625 PPH SS 1
246 2204642 SEAL, UMBRELLA 1
248 2203453 SCREW-3/8-16 X 1.75 SHCS SS NYSHD 4
250 2323436 SCREW-1/4-20 X 1" SHC, SS NYSHIELD 4
252 2294601 SEAL, OUTPUT 1
254 2204618 O-RING, SAE-010, BUNA-N 1
256 2203429 SCREW-1/4-20 X .313 PLASTIC 1
258 2201925 BRACKET, LATCH RELEASE, RIGHT 1
260 2201926 BRACKET, LATCH RELEASE, LEFT 1
262 2207306 BUSHING, LATCH PIN 2
264 2202624 PIN-LATCH, OVERMOLDED 1
266 2202705 SPRING,COMPRSS,1.25 L,0.63 CMP 2
268 2207210 HANDLE, LATCH BRACKET 1
270 3393481 SCREW-#10X.75" PPH HI-LO (SUB) 4
272 2202210 GEAR, 78 TOOTH, OUTPUT TUBE 1
274 2202920 GROMMET, QRP SENSR HARNESS 1
276 2207410 HARNESS, QRP SNSR, HALL EFF 1
278 2200845 CLAMP, TRIM-STEER, L, MACH 1
280 2200846 CLAMP, TRIM-STEER, R, MACH 1
282 2333101 NUT-HEX #10-24 UNC-2B NYL SS 2
284
2206412 COVER, CABLE, STEER HOUSING BLACK *SALTWATER BLACK* 1
2206416 COVER, CABLE, STEER HSG, WHT *SALTWATER WHITE* 1
286 2206413 BACKING, CABLE COVER 1
288 2203441 SCREW-#6 X 1/2" THRD FORM,SSTL 2
290 2332100 SCREW-#8-32 X 3/8 MACHINE 3
292 2383469 SCREW-#10-24 X 3/4,SS,BHCS 2
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
