PARTS DIAGRAM & PARTS LIST
Trim Housing Parts List
Assembly Part # Description Notes Quantity
AA 2997853 ASM, TRIM MOD,SW, WHT,60" *60"* *SALTWATER WHITE* 1
BB 2997854 ASM, TRIM MOD,SW, WHT,72" *72"* *SALTWATER WHITE* 1
CC 2997855 ASM, TRIM MOD,SW, WHT,87" *87"* *SALTWATER WHITE* 1
DD 2997859 ASM, TRIM MOD,SW, WHT,100" *100"* *SALTWATER WHITE* 1
EE 2997856 ASM, TRIM MOD,SW, BLK,60" *60"* *SALTWATER BLACK* 1
FF 2997857 ASM, TRIM MOD,SW, BLK,72" *72"* *SALTWATER BLACK* 1
GG 2997858 ASM, TRIM MOD,SW, BLK,87" *87"* *SALTWATER BLACK* 1
HH 2997860 ASM, TRIM MOD,SW, BLK,100" *100"* *SALTWATER BLACK* 1
Item Part # Description Notes Quantity
320
2206584 HOUSING-MID,TRIM, SW, WHT *SALTWATER WHITE* 1
2206579 HOUSING-MID, TRIM, SW BLK *SALTWATER BLACK* 1
322 2204632 SEAL,LIP,3/4 ID X 1 OD X 1/8 L 1
324 2073414 SCREW-#6-32 X .375 PPH SS(N/A) 2
326 2207335 BUSHING, FLANGED, 3/4 SHAFT 1
328 2205126 BUMPER, WEAR, TRIM 2
330 2207916 HUB, TRIM PULLEY, ANODIZE 1
332 2204631 SEAL,LIP,5/16 ID X 3/4 ODX1/4L 1
334 2203030 RING, RETAIN, TRIM COUNT 1
336 2201727 WASHER, SLIP, TRIM 1
338 2202355 PULLEY, 38T, 1062-20 GROB IN 1
340 2202235 GEAR, PINION, TRIM COUNT 1
342 2202312 SPLINE SHAFT, PULLEY,TRIM 1
344 2201726 WASHER,ID .281, OD .75, T .075 1
346 2203032 RETAINING RING, 1/4" 1
348 2991263 TRIM CORD ASM 1
350 2204619 O-RING, HEYCO, 12X2MM, BUNA-N 1
352 2203102 NUT, PG 9, STRAIN RELIEF 1
354 2204041 SENSOR, TRIM, ROTATIONAL, I 1
356 2202222 GEAR, 12T/35T 1
360 2202223 GEAR, 13T/40T 1
362 2992224 GEAR-TRIM SENSOR,48T, w/MAGNET 1
364 2203500 BOLT-SHOULDER, #8-32 THD, SSTL 2
366 2206442 CAP, TRIM MAGNET SENSOR GEAR 1
368 2372103 SCREW-#6 X .375 PLASTITE SS 1
370 2997014 MOTOR, TRIM, 42MM, RIGHT ANGLE 1
372 2293417 SCREW-1/4-20 X 1.50" BHCS SS 3
374 2206926 GASKET, INSTINCT, TRIM 1
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
