PARTS DIAGRAM & PARTS LIST
Item Part # Description Notes Quantity
376 2202619 PIN-DOWEL, 3/16 X 1/2, SS 2
378
2206589 HSG-MTR CVR, TRIM,SW, WHT *SALTWATER WHITE* 1
2206590 HSG-MTR CVR, TRIM, SW BLK *SALTWATER BLACK* 1
380 2203423 SCREW-#10-24 x .75, SHCS, SS 17
382 2205130 VENT PATCH, YLW/BLK 1
384 2202352 PULLEY-IDLER, TRIM,REAMED 2
386 2201736 WASHER, PLASTIC,.265 ID, .5 OD 4
388 2202610 PIN, BELT PULLEY 2
390 2204635 SEAL,1/16 O-RING CORD,SILICONE 1
392 2201521 COLLAR, OUTPUT TUBE, MACH 1
394 2207336 BUSHING, FLANGED, 1.0 SHAFT 1
396 2200115 LEVER,TRIM RELEASE, MACH. 1
398 2202670 PIN, KNURL, HEAD, 4MM X 8MM 2
400 2202639 PIN-DOWEL, 1/4 X 1.75 LG 1
402 2200818 BELT-LIFT 5MM HTD 1
404
2206523 TRIM HOUSING, OD COVER SW 1
2206524 TRIM HOUSING, OD COVER FW 1
406 2383469 SCREW-#10-24 X 3/4,SS,BHCS 5
408 3393481 SCREW-#10X.75" PPH HI-LO (SUB) 2
410 2200850 CLAMP, TRIM CABLE 1
412 2073414 SCREW-#6-32 X .375 PPH SS(N/A) 2
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
