78 | minnkota.johnsonoutdoors.com ©2023 Johnson Outdoors Marine Electronics, Inc.
PARTS DIAGRAM & PARTS LIST
Mount Parts List
Assembly Part # Description Notes Quantity
JJ 2994948 BAG, ASM, INSTINCT, T3 BL HDW 1
Item Part # Description Notes Quantity
430 2372103 SCREW-#6 X .375 PLASTITE SS 2
432 2201907 BASE, MACHINED, SW 1
434 2205106 PAD, DEAD STOP, STOW 1
436 2373434 SCREW-1/4-20 X 3/4 SS PPMS 2
438 2205518 DECAL-INSTRUCTIONS,TRIM BYPASS 1
440 2323211 STOP-DEAD, DEPLOY 2
442 2383469 SCREW-#10-24 X 3/4,SS,BHCS 6
444 2202907 STANDOFF,.5 ODX.19 IDX.44 L,PL 1
446 2333101 NUT-HEX #10-24 UNC-2B NYL SS 1
448 2203426 SCREW-#10-24 x 1.5 SS BHCS 1
450 2200828 CLIP-CORD BACKUP MT PLATE 1
452 2200829 CLIP-CORD MT BRACKET 1
454
2991245 COIL CORD ASM 45" - 60" *60"* 1
2991246 COIL CORD ASM 72" *72"* 1
2991247 COIL CORD ASM 87" *87"* 1
2991248 COIL CORD ASM 100" *100"* 1
456
✖
STRAIN RELIEF, MOUNT INSTINCT 1
458 2997925 CAM, LATCH, SENSOR w/MAGNET 1
460 2203510 BOLT-SHOULDER,POLYMER,CAM SNSR 1
462 2042711 SPRING-TORSION, SS 1
464 2997814 ASSEMBLY, TILT MOTOR, ULTERRA 1
466 2202326 SUPPORT, TILT SHAFT MID 1
468 2373440 SCREW-#4-24 X 1/4 PHCR SS TY B 3
470 2202930 SPACER, TILT LINKS 2
472 2993300 KNUCKLE,TILT 3/4-8 w/MAG 1
474 2204220 LINK-TILT, LEFT 1
476 2204225 LINK-TILT, RIGHT 1
478 2207331 BUSHING, E-PIN ECCENTRIC 1
480 2203410 SCREW-#10-32 X .5" 4
482 2202324 SUPPORT,TLT SHFT END,REAM 1
484 2207341 BUSHING, RFI-0810-10 1
486 2373481 SCREW-#10-32 X 1/2"SEMS PPH SS 3
488 2263452 SCREW-1/4-20 X 3/4 SHCS S/S 2
490 2073410 SCREW-1/4-20 X 1.125 SHCS SS 2
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
