PARTS DIAGRAM & PARTS LIST
Item Part # Description Notes Quantity
492 2203120 NUT-1/4-20 NYLOK, RIE COATED 2
494 2204030 CTRL BOARD ASM, MAIN ULTERRA 2 1
496 2373487 SCREW-#8-32 X 3/4" PPH MACH SS 4
498 2205412 SHRINK TUBE.75 ID x 2" 1
500 2202623 PIN,QCK REL. 5/16 x 3 1/2 1
502 2052510 CABLE CLAMP, 3/16", NYLON 8
504 2040721 CLAMP-CABLE 3/8" 2
506 2052511 CABLE CLAMP,1/4" VANTAGE 3
508 2073414 SCREW-#6-32 X .375 PPH SS(N/A) 12
510 2203440 SCREW-#4-40 X 1/4 PPH SS 4
512 2373440 SCREW-#4-24 X 1/4 PHCR SS TY B 2
514 2200625 LEADWIRE ASM,8AWG,ULT 2 (DPLX) 1
516 2202919 STRAIN RELIEF, POWER 1
518 2323405 SCREW-1/4-20 X 1/2" MCH SS 2
520 830-123 SCREW-M4 X .7X8MM HEX DBL SEMS 4
522 2294610 SEAL, PCBA TERMINAL GRAY .215 2
524 2294611 SEAL, PCBA TERMINAL BLACK .270 2
526 2203930 RAMP-MOTOR, RIGHT 1
528 2203935 RAMP-MOTOR, LEFT 1
530 2997907 RAMP/ACTUATOR ASM w/MAGNET 1
532 2263453 SCREW-1/4-20 X 1" SHCS S/S 4
534 2202708 SPRING-TORSION,RGT HND WIND,SS 1
536 2372100 SCREW-#8-18 X 5/8 THD* (SS 1
538 2201723 WASHER-#6, .625 OD, SS 1
540
2203921 SIDEPLATE, RIGHT, WHITE *SALTWATER WHITE* 1
2203920 SIDEPLATE, RIGHT, BLACK *SALTWATER BLACK* 1
542
2203926 SIDEPLATE, LEFT, WHITE *SALTWATER WHITE* 1
2203925 SIDEPLATE, LEFT, BLACK *SALTWATER BLACK* 1
544 2323405 SCREW-1/4-20 X 1/2" MCH SS 8
546 2205558 DECAL, SIDEPLATE RIGHT SW 1
548 2205559 DECAL, SIDEPLATE LEFT SW 1
550
2206516 HOUSING-CONTROL, WHITE *SALTWATER WHITE* 1
232344 HOUSING-CONTROL, BLACK *SALTWATER BLACK* 1
552
2205611 DECAL-PWR SWITCH, SW, WHT *SALTWATER WHITE* 1
2205612 DECAL-PWR SWITCH, SW, BLK *SALTWATER BLACK* 1
554 2207311 BUSHING, STEER HOUSING PIVOT 2
556 2202650 SHAFT, SUPPORT, TILT 1
558 2373013 E-RING, EXTERNAL SS .625, HNDL 2
p Not shown on Parts Diagram.
✖ This part is included in an assembly and cannot be ordered individually.
