5. Recovery Float
•The Recovery Float and Filter is located inside of the tank,
•The filter should be checked after each use and cleaned if needed.
•Remove the three screws and the cover, to access screen float for more extensive cleaning.
•Failure to do so will reduce the vacuum performance of the machine.
•Using the machine without it in place or picking up dry material will damage the vacuum
motor.
3 screws
cover
screen/float
