8.1 Programming the 957745 Charger
1. Remove the large rear metal cover on rear the machine.
2. Locate the battery charger.
3. To access the Dip Switches, carefully peal the decal back on the front of the
charger. Start at the bottom left side and peal up. (Removing the plastic charger
cover is not necessary.) Use caution not to damage the decal.
4. There is a series of eight Dip Switches located under the decal.
5. Each switch is numbered 1 through 8.
Dip Switches 1 to 4 are for setting the type of battery.
Type of Battery Switch 1 Switch 2 Switch 3 Switch 4
Lead Acid Wet Batteries ON ON OFF ON
AGM ON OFF OFF ON
Gel and Maintenance Free ON OFF OFF ON
Page 19
