Current (Amperage Output) Switch 5 Switch 6 Switch 7
4 AMPS ON ON NA
8 AMPS OFF ON NA
10 AMPS ON OFF NA
12 AMPS OFF OFF ON
The dip Switches 5,6 and 7 are for selecting the amperage output of the
charger. Use the 12 amp. setting only. * Note: The dip switch # 7 does not
have any function at this time.
Dip Switch 8 is to select the output voltage, either 12 or 24 volt. Use the
24 volt setting only.
Voltage Output Switch 8
12 Volts ON
24 Volts OFF
8.2 Charger Settings (957745)
