The battery needs charging or there is a bad connection to the battery.
Check the connections to the battery. If the connections are good, try
charging the battery.
1 Bar = Low Battery Voltage
2 Bars = Traction Motor Disconnected
There is a bad connection to the Traction motor. Check all
connections between the motor and the control system.
3 Bars = Traction Drive Motor Shorted
There is a short in the Traction Drive circuit. Possible short in the drive
motor or harness.
9.1 E17TD & E20TD Error Codes
Page 33
