Washers may be
rearranged to change the
height of the squeegee
caster.
Note: When adjusting the wheel height, there should always be 5
washers on each wheel assembly in order fully tighten bolts. Move
washers from the top to the bottom of the bracket or visa versa when
making adjustments. See following page.
11.3 Curved Squeegees Only
11. Squeegee Caster Adjustment
(Curved)
Page 42
