7. Charging Indicator (Version 1)
Charge Indicator
•The indicator will light during the
charging process.
•The red light indicates, the
batteries need a full charge.
•The yellow light indicates, the
batteries have received 80% of
their charge.
•The green light indicates, the
batteries are fully charged.
•The red light is flashing, indicates
the charger has detected a fault in
the batteries. (See Section 8.6)
Applies to the 957760 and 957761
chargers only.
Page 17
