7 Bars = Throttle Trip
A throttle trip is indicated. The potentiometer is not detected in circuit or
incorrect resistance value seen by I-drive controller. Test the 5K
potentiometer circuit.
8 Bars = Control System Trip
A control system trip is indicated. Make sure that all connections are secure.
This can also occur if the key switch is turned on and off rapidly
9 Bars = Not Used
9.1 E17TD & E20TD Error Codes
Page 35
