27
2. DIAGNOSTIC PROCEDURE
1. Ensure the shower pullcord / isolator switch is in the OFF position, then turn
ON the pullcord / isolator switch.
2. If the unit ‘Beeps’ & the Start / Stop button is ashing WAIT for 20 SECONDS
until the button stops ashing.
NOTE! If the Start / Stop button continues to ash & no beep was heard
upon start up, refer to ERROR CODE 16 on the fault code sheet.
3. Start the shower & observe light fault indication (if any) & refer to Error Code
Sheet to determine failure and rectify.
NOTE! If the shower operates normally run the unit for at least 5 minutes
at showering temperature & ensure the temperature remains stable.
4. Turn the shower off at the Start / Stop Button & observe ‘phased shutdown’.
DO NOT isolate the power at the pullcord / isolator switch until the water ow
stops.
5. Turn off the power at the pullcord / isolator switch, then turn the power back
on and commission the shower.
6. Run the shower for at least 5 minutes.
7. Show the user the correct start / stop procedure and general operation of the
shower. Advise user that isolating the shower before the ow has stopped
may damage the shower.
For the fault codes 0 to 14 and 18, the reset light will be on or ashing. This will
require the shower to be turned off at the pullcord / isolator switch to reset
the unit. When the pullcord / isolation switch is turned back on the shower
may beep and the Start / Stop button may ash. If this occurs go back to
action number 2 and re-follow the Diagnostic Procedure.
