9
Dimensions
Advance ATL
Standard / Memory
Advance ATL Flex / Flex Extra /
Flex Extra Wireless
403 mm
184 mm
87.5 mm
71 mm
403 mm
184 mm
102 mm
71 mm
INSTALLATION REQUIREMENTS
General
We recommend that the product be brought into the room where it is to be installed
and left to acclimatise to room temperature, this will reduce the possibility of
condensation on electronic components.
The shower works best when water supply conditions are stable and within the
specications, refer to section 'Specications'. If the supply conditions fall outside
the specications, the shower may go into a safe shut down condition.
If pipework and/or electrical cables enter the shower from the rear through a hole in
the wall, provision must be made to prevent water ingress back into the wall structure.
Route cable and pipe supplies via the cut outs moulded in the case and cover.
DO NOT increase the size or cut alternative pipe / cable entry points as water ingress
into the product may occur.
1. Plumbing
Refer to section: 'Important Safety Information' rst.
1.1 Do not use sealing compounds on any pipe ttings or joints.
1.2 To avoid damage to the case when soldered ttings are used, pre-solder the
pipework and ttings before connecting them to the inlet connector assembly.
1.3 Never t the appliance to hot water supplies or to gravity systems of any
description. Only t the product to a mains cold water pipe.
