WIRING DIAGRAM
Relay
Board
N
Inlet Sensor
Red
Brown
Solenoid Valve
230/240 V
AC Only
Brown
Double Pole Switch
45A Break Capacity
3 mm Contact Separation
L
E
Control Board
CN8
Green/Y
Terminal
Block
Outlet
Temperature
Sensor
One Shot
Thermal Switch
Blue
Heater Tank
Plumbing
Connectors
Outlet
Inlet
Pump Driver
Board
(Fitted to Standard Extra and Flex Extra models only.)
(Fitted to Standard Extra and Flex Extra models only.)
CN7
CN4
CN6
CN2
CN3
CN3
CN1
CN1
CN10
CN3
CN4
CN12
CN11
Blue
Radio
PCB
