Mira Advance Installation Guide

16
1306246-W2-A
Connect the hose pointing into the bath
or tray.
Note! Make sure that the hose washer
is tted.
DO NOT t the shower head at this stage.
Connect supply pipe, then turn the water
supply on and check the shower unit for
leaks. DO NOT overtighten.
9
Drill the xing holes through the plastic case in the designated areas as required.
Route the signal cable to the shower drain pump (if applicable).
Fix the appliance to the wall.
Use appropriate screws and wall plugs for xing.
Note! Make sure that the product is securely xed to the wall.
8
7

Mira Advance Specifications

General

Temperature Control	Thermostatic
Warranty	2 Years
Power Ratings	9.8 kW
Water Connection	15 mm
Outlet Connection	1/2"
Water Pressure	0.7 - 10 bar
Cable Entry Points	Bottom entry
Safety Features	Overheat protection
Approvals	WRAS
