SPECIFICATIONS
5-2
Mirage 2000/4000/6000 User’s Manual
Number of inputs 2 RGBHV
(2
nd
input via plug-in module)
2 video
(requires optional video decoder module)
Analog RGB and YP
b
P
r (INTERLACED [non-3D] OR PROGRESSIVE SCAN FORMAT)
Horizontal frequency range * 15 – 120 kHz
Vertical frequency range * 23.97 – 120 Hz
Pixel clock rate (digitizing sample rate) 10 – 160 MHz
Signal format Analog RGB or YP
b
P
r
Active pixels per scan line (H) 640 – 2048 (1280 in 3D mode)
Active lines per frame/field (V) 200 – 2000 (1024 in 3D mode)
Minimum Back Porch in 3D mode 350 ns (H) and 6 lines (V)
Minimum Front Porch in 3D mode 4 pixels (H) and 1 line (V)
Input levels
R,B,G,Y — with sync
R,G,B — without sync
Pb,Pr
(NOTE: not available in 3D mode)
1.0V
p-p
±2 dB
0.7V
p-p
±2 dB
0.7V
p-p
±2 dB
DC offset ± 5V
Nominal impedance 75 ohms
Maximum return loss (VSWR) 1.2:1 dB @ 200 MHz
* Input frequencies higher than the maximum panel refresh rate will be displayed at a lower rate.
Analog Video
(OPTIONAL)
Signal formats Composite (CVBS), S-Video (Y/C)
Video standards NTSC, NTSC 4.43, PAL, PAL-M,
PAL-N, PAL-60 & SECAM
Composite/S-Video luminance bandwidth 5.5 MHz
Input level, Composite 1.0 V
p-p
± 3db
(including sync tip)
Input level, S-Video, Luma (Y) 1.0 V
p-p
± 3db
(including sync tip)
Input level, S-Video, Chroma (C) 630 mV
p-p
nominal (burst)
DC offset ± 5V
Nominal impedance 75 ohms
Maximum return loss (VSWR) 1.2:1 dB @ 6 MHz
Sync
(INTERLACED OR PROGRESSIVE SCAN FORMAT)
Input level 0.5V
p-p
– 5.0V
p-p
DC operating range 0V – 5V
Impedance
(for composite or separate H & V)
75 ohms nominal
Sync type
• Separate H and V
• Bi-level or tri-level sync-on-green
• Bi-level or tri-level composite
Polarity Positive or negative
Maximum return loss (VSWR) 1.2:1 dB @ 200 MHz
RS-232 Serial Input / Output
Number of connectors 3 (1 ntwrk in, 1 ntwrk out, 1 for switcher)
Connector type 9 pin “D”
RS-422 Serial Input / Output
Number of connectors 2
Connector type 6-pin XLR
Wired Control Input
Optional wired keypad 3-pin XLR connector
In
p
uts / Out
p
uts
'
