Mirage 2000 - 3.6 Adjusting the Image

OPERATION
3-22
Mirage 22000/4000/6000User’s Manual
• CHANNEL NAME:
An alpha-numeric label can be defined and/or changed
here. Channel names can be up to 12 characters in length.
•
CHANNEL NUMBER:
A channel number from 01 to 99 can be changed
here. NOTE: If you enter a channel number that already exists, a dialog
message appears indicating that this number is already in use–assign a
different channel number.
•
SWITCHER NUMBER: “
0” represents the projector itself. Or, if the input
source is connected to a switcher, the default will be the lowest switcher
number available (from 1-9)–change here as desired.
•
SLOT: 1 (
Input1
), 2 (
Input2
), 3 (
Input3
), or 4 (
Input4
) for projector inputs, or
current slot number (1-9) if the source is connected to a switcher.
•
LOCKED: If checked, all of the image settings for this channel are disabled.
If unchecked (default), all available image settings can be adjusted as
desired. You cannot use Auto Setup with a locked channel.
•
IN MENU: If checked (default, except for automatically defined channels
with unchanged parameters), this defined channel will then appear in the
list available when
Chan
key is pressed. If unchecked, the channel must be
accessed via
Chan
on the keypad or via the Auto Source function. NOTE:
On-screen display of the channel list is an option that must be set in the
Menu Preferences menu.
• AUTO SOURCE:
If checked, (default), the projector can automatically
locate this channel when an incoming input signal matches. If not
checked, the projector can locate the selected channel only when it is
directly selected via
Chan
on the keypad—and a change in input signal will
not result in a channel change.
•
PREVIOUS CHANNEL: Select this option to see or change Channel Edit
settings for the previous channel in the Channel Setup list.
•
NEXT CHANNEL:
Select this option to see or change Channel Edit settings
for the next channel in the Channel Setup list.
Most options for source-specific image adjustments can be accessed through two
menus: Size and Position (
Menu
) and Image Settings (
Menu
), both of which are
listed in the Main menu. While in either of these two menus, you can change settings
affecting the image from the current channel by working with the appropriate
slidebars, checkboxes and pull-down lists.
Exit
will always return to the previous
menu (or to the presentation, if from the Main menu) and accept any changes you
may have made. Or you may prefer to begin with an automated setup in which the
projector quickly defines certain parameters for you—select Auto Setup from the
Main menu. These settings can then be fine-tuned in Size and Position and Image
Settings at any time.
From your presentation, access any of the individual options in these menus by
pressing
Menu
followed by the appropriate two-digit number representing their
location in the menu system. For example, press
Menu
to quickly access the
“Color Setup” option in the Image Settings menu.
3.6 Adjusting the
