Section 2
Installation & Setup
Mirage 2000/4000/6000 User’s Manual
2-1
This section explains how to install and set up your projector. If you are familiar with the projector and want to
quickly set it up for temporary use, follow the Quick Setup instructions below.
NOTES: 1) The lens is not installed for shipping. For instructions on how to install or replace a lens, refer to 4.5,
Replacing the Lens. 2) This section assumes that the optional video decoder module is installed.
Follow these steps for quick setup of the projector in a standard floor mount position.
Position the Projector
Set the projector at the expected throw distance (projector-to-screen distance) and
vertical position. See 2.3, Projector Position and Mounting and Appendix E. Make
sure that the projector is level from side-to-side (see 2.7, Leveling) and lens cap is off.
Connect a Source
Locate the main input panel at the rear of the projector. The lower left area, labeled
INPUT 1
, accepts an RGB input via BNC connectors. The upper right area (assuming
a video decoder is installed) accepts a composite video at
INPUT 3 or S-video input at
INPUT 4. Connect your source to the appropriate panel connectors.
Connect the Line Cord to AC Power
Connect the projector’s line cord to the AC receptacle at the lower right rear corner of the
projector and to proper AC. The Mirage 2000 requires input power of 100-240 VAC, 50-
60 Hz @ 9 amps (@ 100 V). The Mirage 4000 requires input power of 100-240 VAC, 50-
60 Hz @ 11.5 amps (@ 100 V). The Mirage 6000 requires input power of 200-240 VAC,
50-60 Hz @ 8.5 amps (@ 200 V). Use the line cord provided with the projector. See
Section 5.
WARNING
Do not attempt operation if the AC supply and cord are not
within the specified voltage and power range. See Section 5.
Turn the Projector ON
Using either the built-in or remote keypad, press
Power*
and hold for approximately 1
second to turn the projector on (or press
Power*
ON
). Let the projector warm up for
about five minutes. The
POWER
LED, located in the lower right corner of the rear
input panel, should glow a steady green.
Select a Source
Using either the built-in or remote keypad, press
Input1
,
Input2
,
Input3
, or
Input4
to select
and display the image for the source you connected in Step 2. The display will resize
as needed, producing an image as large as possible for the type of source present.
2.1 Quick Setup
STEP 1
'
STEP 2
'
STEP 3
'
STEP 4
'
STEP 5
'
