Configuration
Version 2.7 TX3 Telephone Access System Programming Manual 47
LT-979 Copyright 2018
To define outputs
1. Press the arrow key to scroll to Outputs, and press the enter (telephone)
key. The Output selection appears.
2. Press the arrow key to scroll to the output you wish to configure and press
the telephone (enter) key. The Output Active State selection appears.
3. Press the arrow key to scroll to the input you wish to configure and use the
“#” key to define the output state as energized or de-energized.
4. Press the telephone (enter) key. The Output selection appears.
5. Proceed with the rest of the input configuration or
6. Press info key to return to previous menu.
2.14 Correlations
The Correlation selection lets you associate specific input events with specific
output actions.
To configure a correlation
1. Press the arrow to scroll to “Correlations” in the main configuration menu
and press the enter (telephone) key. The “Correlation” selection appears.
Output Types
1 Main Door lock
2 Aux Door lock
3 GP Output 3
4 GP Output 4
Opt Active State
< > De-energized
< x > Energized
Correlation
1 Add
2 Edit
3 Delete
