90
8575
8575
N/B Maintenance
N/B Maintenance
Figure 2-22 Remove the base unit cover Figure 2-23 Remove the metal shield
4. Lift up the base unit cover and disconnect the touch pad cord. (Figure 2-22)
5. Remove the four screws fastening the base unit. (Figure 2-23)
