Mitsubishi Electric FR-F800 Series User Manual

120
4. BASIC OPERATION
4.4 Frequently-used parameters (simple mode parameters)
4.4 Frequently-used parameters (simple mode
parameters)
Parameters that are frequently used for the FR-F800 series are grouped as simple mode parameters.
When Pr.160 User group read selection = "9999", only the simple mode parameters are displayed on the operation panel.
This section explains the simple mode parameters.
4.4.1 Simple mode parameter list
For simple variable-speed operation of the inverter, the initial values of the parameters may be used as they are. Set the
necessary parameters to meet the load and operational specifications. Parameter's setting, change and check can be made
on the operation panel (FR-DU08).
• Pr.160 User group read selection can narrow down the displayed parameters to only the simple mode parameters. Set
Pr.160 User group read selection as required. (To change the parameter setting, refer to page 116.)
Pr.160 setting Description
9999 (FM type initial value) Only simple mode parameters are displayed.
0 (CA type initial value) All parameters (simple mode parameters and extended parameters) are displayed.
1 Only parameters registered in user groups are displayed.
Pr. Pr. group Name Increment
Initial value
*11
Range Application
Refer
to
page
FM CA
0 G000 Torque boost 0.1%
6%
*1
0% to 30%
Set this parameter to obtain a higher starting
torque under V/F control. Also set this when a
loaded motor cannot be driven, the warning
"OL" occurs, and the inverter output is shut off
with the fault indication "E.OC1".
551
4%
*2
3%
*3
2%
*4
1.5%
*5
1%
*6
1 H400
Maximum
frequency
0.01 Hz
120 Hz
*7
0 to 120Hz Set the upper limit for the output frequency.
287
60Hz
*8
2 H401
Minimum
frequency
0.01 Hz 0 Hz 0 to 120 Hz Set the lower limit for the output frequency.
3 G001 Base frequency 0.01 Hz 60 Hz 50 Hz 0 to 590 Hz
Set this parameter when the rated motor
frequency is 50 Hz. Check the rating plate of
the motor.
552
4 D301
Multi-speed
setting (high
speed)
0.01 Hz 60 Hz 50 Hz 0 to 590 Hz
Pre-set the speeds that will be switched
among by terminals.
125,
130,
263
5 D302
Multi-speed
setting (middle
speed)
0.01 Hz 30 Hz 0 to 590 Hz
6 D303
Multi-speed
setting (low
speed)
0.01 Hz 10 Hz 0 to 590 Hz
7F010
Acceleration
time
0.1 s
5 s
*9
0 to 3600 s Set the acceleration time.
228
15 s
*10
8F011
Deceleration
time
0.1 s
10 s
*9
0 to 3600 s Set the deceleration time.
30s
*10
9
H000
C103
Electronic
thermal O/L
relay
0.01 A
*7
Inverter rated
current
0 to 500 A
*7
Protects the motor from heat.
Set the rated motor current.
266
0.1A
*8
0 to 3600A
*8
79 D000
Operation mode
selection
1 0 0 to 4, 6, 7
Select the start and frequency command
sources.
240
