1. INTRODUCTION
1 INTRODUCTION
The contents described in this chapter must be read before using this product.
Always read the instructions before use.
For the separated converter type, refer to the "INTRODUCTION" in the FR-F802 (Separated Converter Type) Instruction
Manual (Hardware).
For the IP55 compatible model, refer to the "INTRODUCTION" in the FR-F806 (IP55/UL Type 12 specification) Instruction
Manual (Hardware).
 Abbreviations
 Trademarks
• Microsoft and Visual C++ are registered trademarks of Microsoft Corporation in the United States and other countries.
• MODBUS is a registered trademark of SCHNEIDER ELECTRIC USA, INC.
• BACnet is a registered trademark of the American Society of Heating, Refrigerating and Air-Conditioning Engineers
(ASHRAE).
• LONWORKS is a registered trademark of Echelon Corporation in the United States and other countries.
• Other company and product names herein are the trademarks and registered trademarks of their respective owners.
 Notes on descriptions in this Instruction Manual
• Connection diagrams in this Instruction Manual appear with the control logic of the input terminals as sink logic, unless
otherwise specified. (For the control logic, refer to page 64.)
 Harmonic suppression guidelines
All the models of the inverters used by specific consumers are covered by "the Harmonic Suppression Guidelines for
Consumers Who Receive High Voltage or Special High Voltage". (For details, refer to page 98.)
Item Description
DU Operation panel (FR-DU08)
Operation panel Operation panel (FR-DU08) and LCD operation panel (FR-LU08)
Parameter unit Parameter unit (FR-PU07)
PU Operation panel and parameter unit
Inverter Mitsubishi Electric inverter FR-F800 series
Pr. Parameter number (Number assigned to function)
PU operation Operation using the PU (operation panel/parameter unit)
External operation Operation using the control circuit signals
Combined operation Combined operation using the PU (operation panel/parameter unit) and External operation
Mitsubishi Electric standard
motor
SF-JR
Mitsubishi Electric constant-
torque motor
SF-HRCA
Mitsubishi Electric IPM motor MM-EFS motor and MM-THE4 motor
MM-EFS 1500 r/min spec. MM-EFS motor with speed rating of 1500 r/min
MM-EFS 3000 r/min spec. MM-EFS motor with speed rating of 3000 r/min
Downloaded from ManualsNet.com search engine

Mitsubishi Electric FR-F800 Series Specifications

General

Series	FR-F800
Category	Inverter
Power Range	0.4kW to 630kW
Output Frequency	0 to 400Hz
Rated Output Current	Varies by model (refer to specifications)
Control Method	V/f control, Vector control
Communication Options	RS-485
Protection Features	Overload, Short circuit
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in or external options available
Cooling Method	Forced air cooling
Ambient Temperature	-10°C to 50°C
Storage Temperature	-20°C to 65°C
Humidity	Up to 95% (non-condensing)
Altitude	Up to 1000m
Enclosure Rating	IP20 (standard)
Dimensions	Varies by model
