5. PARAMETERS
5.8 (M) Item and output signal for monitoring
1
2
3
4
5
6
7
8
9
10
5.8 (M) Item and output signal for monitoring
5.8.1 Speed indication and its setting change to
rotations per minute
The frequency monitored or set on the operation panel can be changed to the motor speed or the machine speed.
Purpose Parameter to set
Refer to
page
To display the motor speed (the number of
rotations per minute)
To switch the unit of measure to set the
operation speed from frequency to motor
speed
Speed indication and its
setting change to
rotations per minute
P.M000 to P.M002 Pr.37, Pr.144, Pr.505 303
To change the item monitored on the
operation panel and parameter unit
Operation panel monitor
item selection
Cumulative monitor
value clear
P.M020 to P.M023,
P.M030, P.M031,
P.M044, P.M045,
P.M050 to P.M052,
P.M100 to P.M104
Pr.52, Pr.170,
Pr.171, Pr.268,
Pr.290, Pr.563,
Pr.564, Pr.774 to
Pr.776, Pr.891,
Pr.992, Pr.1018,
Pr.1106 to Pr.1108
305
To change the monitor item whose data is
output via terminal FM (CA) or AM
Terminal FM (CA)
function selection
P.M040 to P.M042,
P.M044, P.M300,
P.M301, P.D100
Pr.54, Pr.55, Pr.56,
Pr.158, Pr.290,
Pr.291, Pr.866
314
To adjust the output via terminal FM (CA) or
AM
Terminal FM (CA)/AM
calibration
P.M310, P.M320,
P.M321, P.M330 to
P.M334
Pr.867, Pr.869, C0
(Pr.900), C1
(Pr.901), C8 (Pr.930)
to C11 (Pr.931)
319
To check the effects of energy saving
Energy saving
monitoring
P.M023, P.M100,
P.M200 to P.M207,
P.M300, P.M301
Pr.52, Pr.54, Pr.158,
Pr.891 to Pr.899
324
To assign functions to the output terminals
Output terminal function
assignment
P.M400 to P.M406,
P.M410 to P.M416,
P.M420 to P.M422,
P.M431
Pr.190 to Pr.196,
Pr.289, Pr.313 to
Pr.322
330
To detect the output frequency
Up-to-frequency
sensitivity
Output frequency
detection
Low speed detection
P.M440 to P.M444
Pr.41 to Pr.43, Pr.50,
Pr.870
337
To detect the output current
Output current detection
Zero current detection
P.M433, P.M460 to
P.M464
Pr.150 to Pr.153,
Pr.166, Pr.167
339
To detect the output torque Output torque detection P.M470 Pr.864 341
To use the remote output function Remote output P.M500 to P.M502 Pr.495 to Pr.497 341
To use the analog remote output function Analog remote output P.M530 to P.M534 Pr.655 to Pr.659 343
To output the fault code via a terminal
Fault code output
function
P.M510 Pr.76 345
To detect the specified output power
Pulse train output of
output power
P.M520 Pr.799 346
To detect the control circuit temperature
Control circuit
temperature monitoring
P.M060 Pr.663 347
Pr. Name
Initial value
Setting range Description
FM CA
37
M000
Speed display 0
0 Monitoring and setting of frequency
1 to 9998
*1
Set a number for the speed of machine operated at the
speed (frequency) set in Pr.505.
505
M001
Speed setting
reference
60 Hz 50 Hz 1 to 590 Hz Set the reference speed (frequency) for Pr.37.
144
M002
Speed setting
switchover
4
0, 2, 4, 6, 8, 10, 12, 102,
104, 106, 108, 110, 112
Set the number of motor poles for the indication of the
motor speed.
