Mitsubishi Electric FR-F800 Series User Manual

656
8. SPECIFICATIONS
8.4 Outline dimension drawings
8.4.2 Dedicated motor outline dimension drawings
 Premium high-efficiency IPM motor [MM-EFS (1500 r/min specification)]
•30K or lower
• 37K to 55K
Z
X
Frame leg viewed from underneath
Sliding distance
Cross section C-C
R
F F
N
XB
A B
KA
Q
QK
S
U
W
KD
D
E E
M
H
C
0
-0.5
C
C
KL
KG
T
Model
Output
(kW)
Frame
number
Outline dimension (mm)
A B C D E F H KA KD KG KL M N XB Q QK R S T U W X Z
200 V class
MM-EFS[]1M
400 V class
MM-EFS[]1M4
7 0.75 80M 122 93 80 162 62.5 50 166 39.5 27 63 145 160 125 50 40 32 140 φ19j6 6 3.5 6 15 9
15 1.5 90L 143 111.5 90 184 70 62.5 191 53 27 76 158 175 150 56 50 40 168.5 φ24j6 7 4 8 15 9
22 2.2 100L 173 128 100 207 80 70 203.5 65 27 88 169 200 180 63 60 45 193 φ28j6 7 4 8 4 12
37 3.7 112M 181 135 112 228 95 70 226 69 27 103 180 230 180 70 60 45 200 φ28j6 7 4 8 4 12
55 5.5 132S 211.5 152 132 266 108 70 265 75 27 120 197 256 180 89 80 63 239 φ38k6 8 5 10 4 12
75 7.5 132M 230.5 171 132 266 108 89 265 94 27 120 197 256 218 89 80 63 258 φ38k6 8 5 10 4 12
11K 11 160M 252 198 160 318 127 105 316 105 56 142 266 310 254 108 110 90 323 φ42k6 8 5 12 4 14.5
15K 15 160L 274 220 160 318 127 127 316 127 56 142 266 310 298 108 110 90 345 φ42k6 8 5 12 4 14.5
18K 18.5
180M 292.5 225.5 180 363 139.5 120.5 359 127 56 168 289 335 285 121 110 90 351.5 φ48k6 9 5.5 14 4 14.5
22K 22
30K 30 180L 311.5 242.5 180 363 139.5 139.5 359 146 56 168 289 335 323 121 110 90 370.5 φ55m6 10 6 16 4 14.5
C
C
R
BA
KA
F F
N
XB
70
E E
M
140
110
11
C
0
-0.5
H
KG
φ
90
D
30
M16 screw
Cross section C-C
S
W
T
U
Frame leg viewed from underneath
Sliding distance
18.5
4
KP
9
Model
Output
(kW)
Frame
number
Outline dimension (mm)
A B C D E F H KA KG KP M N XB R S T U W
200 V class
MM-EFS[]1M
400 V class
MM-EFS[]1M4
37K 37
200L 355 267.5 200 406 159 152.5 401 145 472 548 390 361 133 425.5 φ60m6 11 7 18
45K 45
55K 55 225S 365 277 225 446 178 143 446 145 517 593 428 342 149 432 φ65m6 11 7 18
