6. PROTECTIVE FUNCTIONS
6.6 Check first when you have a trouble
6.6.14 Power lamp is not lit
Check
point
Possible cause Countermeasure
Refer to
page
Main
circuit
Control
circuit
The wiring or installation is inadequate.
Check for secure wiring and installation.
The power lamp is lit when power is supplied to the control circuit (R1/
L11, S1/L21).
49
