ENGINE ELECTRICAL
-
Ignition System
IGNITION
SYSTEM
16-31
SPECIFICATIONS
GENERAL SPECIFICATIONS
CRANK ANGLE SENSOR
cup
to 1992
model>
Items
Specifications
Type
Contact pointless type
Identification No.
Tl
T49371
Part No.
MD1 53464
Advance mechanism
Firing order
Controlled by engine control unit
l-2-3-4-5-
6
IGNITION COIL
r
Items
Type
Identification No.
Specifications
Mold
3-coil
F-536
L
I
Part No.
j
MD152648
I
SPARK PLUG
Items
NGK
-
Specifications
PFRGJ-11
NIPPON DENS0
PK20PRPll
SERVICE SPECIFICATIONS
Items
Ignition coil
Standard value
Limit
Primary coil resistance at
20°C
0.67-0.81
(68°F)
R
Secondary coil resistance at
11.3-15.3
20°C
(68°F)
kc2
Spark plug gap mm (in.)
1.0-l
.l
(0.39-0.43)
Spark plug cable
kQ
1.3
(.051)
Max. 22
SPECIAL
TOOLS
Tool number and name
Supersession
Application
i
MD998464
Harness connector
(4 pin, square)
Check of ignition primary
voltage
(connection of ignition coil
connector)
i
TSB Revision
476
478
