Mitsubishi 3000GT - Ignition Switch Removal and Installation; Ignition Switch Segment Removal Steps; Special Tool; Steering Lock Cylinder Removal Steps

54-6
CHASSIS ELECTRICAL - Ignition Switch
IGNITION SWITCH
SPECIAL TOOL
Tool Tool number and name
Supersession Application
MB990803
Steering wheel puller
General service tool Removal of steering wheel
IGNITION SWITCH
REMOVAL AND INSTALLATION
40 Nm
29 ft.lbs.
6 Nm
6
Steering lock cylinder removal
steps
Ignition switch segment removal
steps
1. Air bag module (Refer to GROUP 52B
4Ab
- Air Bag Module and Clock Spring.)
3. Knee protector
2. Steering wheel
(Refer to GROUP 52A - Instrument
3. Knee protector
Panel.)
LRedE;)to GROUP 52A - Instrument
:i:
4. Column cover, lower
5. Column cover, upper
:::
4. Column cover, lower
6. Lap cooler duct and foot shower duct
5. Column cover, upper
10. Key reminder switch segment
6. Lap cooler duct and foot shower duct
11. Ignition switch segment
,A+ 7. Column switch and clock spring
assembly
NW
8. Ignition key illumination ring
9. Steering lock cylinder
TSB Revision
