CIRCUIT DIAGRAMS - How to Read Circuit Diagrams
WIRE COLOR CODES
Wire colors are identified by the following color codes.
Code Wire color
Code Wire color
1 B 1 Black
1 P 1 Pink
I
BR Brown
R Red
G Green
SB Sky blue
I~-- I
GR Gray
v
Violet
I
1 L 1 Blue
1 W 1 White
I
LG
Light green
0 Orange
Y Yellow
Example: e+ 1.25 5-E
-i-
1 2 cl
Al660244
-1
If a cable has two colors, the first of the two color code
characters indicates the basic color (color of the cable coating)
and the second indicates the marking color.
No.
1
2
3
4
NOTE
Meaning
<F>: Flexible wire
<TX Twisted wire
Wire size (mm*)
Basic color (color of the cable coating)
Marking color
*: No code indicates 0.5 mm2 (.0008 in.2).
Cable color code in parentheses indicates 0.3 mm2
(.0005 in.2).
TSB Revision
