Mitsubishi 6A1 series

6A1 ENGINE (E-W) -
Intake Manifold and Exhaust Manifold
11A-8-2
REMOVAL AND INSTALLATION <MIVEC>
1
2
3
4
5
6
7
8
9
13 Nm
17 Nm
44 Nm
49 Nm
49 Nm
13 Nm
Removal steps
1. Intake manifold
2. Gasket
3. Heat protector, right
4. Exhaust manifold stay
5. Exhaust manifold, right
6. Gasket
7. Heat protector, left
8. Exhaust manifold, left
9. Gasket
PWEE9622
E
Feb. 1997Mitsubishi Motors Corporation
