6A1 ENGINE (E-W) -
Specifications
11A-1-4
TORQUE SPECIFICATION
Items Nm
Alternator and drive belt
Alternator pivot nut 44
Alternator bolt 21
Oil level gauge guide 23
Tensioner pulley 15
Engine hanger 23
Tensioner pulley bracket A 45
Crankshaft bolt 182
Engine cover 3
Timing belt
Timing belt front cover 11
Engine support bracket 49
Angle sensor 9
Angle sensor connector bracket 11
Tensioner pulley 48
Tensioner arm 24
Auto tensioner 21
Camshaft sprocket bolt 88
Idler pulley 35
Timing belt rear cover 11
Angle sensor connector bracket 11
Fuel and emission control parts
Air intake plenum stay 18
Connector bracket 11
EGR valve 22
Throttle body 12
Air intake plenum 18
Delivery pipe 12
Fuel pipe 9
Fuel pressure regulator 9
Alternator bracket 23
PWEE9622
E
Feb. 1997Mitsubishi Motors Corporation
