6A1 ENGINE (E-W) -
Cylinder Head and Valves
11A-12-3
REMOVAL SERVICE POINTS
PRECAUTION FOR REMOVED PARTS
Keep removed parts in order according to the cylinder number
and intake/exhaust side.
A
A
"
CYLINDER HEAD BOLT REMOVAL
(1) Using the special tool, loosen the cylinder head bolts.
Loosen evenly, little by little.
A
B
"
RETAINER LOCK REMOVAL
(1) Store removed valves, springs and other parts, tagged
to indicate their cylinder Nos. and location for reassembly.
PWEE9622
E
Feb. 1997Mitsubishi Motors Corporation
6AE0166
<SOHC>
MB991653
6AE0408
<MIVEC>
MB991653
6AE0167
<SOHC>
MD998772
6AE0253
<MIVEC>
MD998784
MD998772
6EN1068
MD998735
To Next Page
