6A1 ENGINE (E-W) -
Rocker Arm and Camshaft <SOHC>
11A-9-1
9. ROCKER ARM AND CAMSHAFT <SOHC>
REMOVAL AND INSTALLATION
Apply engine oil to all
moving parts before
installation.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
4Nm
24 Nm
31 Nm
12
12
9
9
8
8
7
7
Removal steps
1. Rocker cover
2. Rocker cover gasket
3. Oil seal
"
D
A 4. Oil seal
A
A
""
C
A 5. Rocker arm and rocker shaft
A
A
""
C
A 6. Rocker arm and rocker shaft
"
C
A 7. Rocker shaft spring
8. Rocker arm A
9. Rocker arm B
10. Rocker arm shaft
"
B
A 11. Lash adjuster
12. Rocker arm C
13. Rocker arm shaft
"
B
A 14. Lash adjuster
15. Thrust case
16. O-ring
"
A
A 17. Camshaft
PWEE9622
E
Feb. 1997Mitsubishi Motors Corporation
