6A1 ENGINE (E-W) -
Specifications
11A-1-5
Items Nm
Ignition system
Spark plug 25
Water cover (SOHC) 11
Distributor (SOHC) 13
Ignition failure sensor (MIVEC) 10
Condenser bracket assembly (MIVEC) 5
Ignition coil (MIVEC) 10
Water pump and water pipe
Engine hanger (MIVEC) 11
Engine coolant temperature gauge unit 11
Engine coolant temperature sensor 29
Heater pipe (SOHC) 23
Water inlet fitting 18
Water outlet fitting 18
Thermostat housing 23
Water pipe 13
Water pump 23
Intake manifold and exhaust manifold
Intake manifold 17
Heat protector 13
Exhaust manifold stay 44
Exhaust manifold 49
Rocker arm and camshaft <SOHC>
Rocker cover 4
Rocker arm and rocker shaft 31
Thrust case 24
Rocker arm and camshaft <MIVEC>
Rocker cover 4
Oil control valve holder 9
Cam cap 24
Bearing cap M6 11
Bearing cap M8 24
PWEE9622
E
Feb. 1997Mitsubishi Motors Corporation
