NOTE
l
The high-beams can also flash when the
lamp switch is OFF.
l
If you turn the lamps off with the headlamps
set to high-beam, the headlamps are auto-
matically returned to their low-beam setting
when the lamp switch is next turned to the
“ ” position.
Automatic High-Beam (AHB)*
The system switches the headlamp beams
(high/low) when the sensor (A) senses an il-
luminant such as lights of a vehicle in front
or oncoming vehicle or street lamp.
For details about handling the sensor, refer to
“Handling of the sensor” on page 6-53.
WARNING
l
The headlamp beams (high/low) may not
be switched automatically under certain
circumstances. Do not overestimate the
system. It is the responsibility of the driv-
er to switch the headlamp beams (high/
low) manually to suit each driving condi-
tion.
Refer to “Dipper (High/Low beam
change)” on page 5-52.
How to use the AHB
1. Rotate the lamp switch to “ ” position
or “AUTO” position when the engine is
running.
2. Press the AHB switch.
The AHB is activated and the indicator
will illuminate.
If the AHB switch is pressed again, the
AHB will be deactivated and AHB indi-
cator will go off.
NOTE
l
If the headlamps are on when the lamp
switch is in the “AUTO” position, the AHB
works.
l
You can switch the headlamp beams (high/
low) manually by operating the lever even if
the AHB is working.
Refer to “Dipper (High/Low beam change)”
on page 5-52.
If the lever is operated manually, the AHB
indicator will go off and the AHB will be de-
activated.
Refer to “Manual switching” on page 5-53.
l
The AHB is not deactivated when you pull
the lever slightly (operation of the headlamp
flasher).
Combination headlamps and dipper switch
5-53
OGAE19E1
Instruments and controls
5
