Mitsubishi FR-E520-0.1KN

PARAMETERS
131
<Setting>
Refer to the following list and set the parameters.
Setting
Terminal
Name
Function
Related
Parameters
Operation
Command
0 RL Low-speed operation command
Pr. 4 to Pr. 6
Pr. 24 to Pr. 27
Pr. 232 to Pr. 239
Both
1 RM Middle-speed operation command
Pr. 4 to Pr. 6,
Pr. 24 to Pr. 27,
Pr. 232 to Pr. 239
Both
2 RH High-speed operation command
Pr. 4 to Pr. 6,
Pr. 24 to Pr. 27,
Pr. 232 to Pr. 239
Both
3 RT Second function selection Pr. 44 to Pr. 50 Both
6 MRS Output shut-off
Pr. 57, Pr. 58,
Pr. 162 to Pr. 165
Both
7OH
External thermal relay input*
The external thermal relay provided for
overheat protection or the embedded
temperature relay within the motor is
activated to stop the inverter.
Only Pr. 183 may
be set.
External
8REX
15-speed selection (combination with
three speeds of RL, RM, RH)
Pr. 4 to Pr. 6,
Pr. 24 to Pr. 27,
Pr. 232 to Pr. 239
Both
18 X18
General-purpose magnetic flux vector-
V/F switch-over (OFF: general-purpose
magnetic flux vector control, ON: V/F
control) (Note 3)
Pr. 80 Both
*: Activated when the relay contact "opens".
[Explanation of table]
Both : Control from both external terminal and PLC is valid.
External : Control by signal from external terminal is only valid.
Note: 1. One function can be assigned to two or more terminals (remote output). In
this case, the terminal (remote output) inputs are ORed.
2. The speed command priorities are higher in order of multi-speed settings
(RH, RM, RL, REX).
3. When V/F control is selected using the V/F-general-purpose magnetic flux
switch-over function, the secondary functions are also selected.
During operation, you cannot switch between V/F and general-purpose
magnetic flux. Should you switch between V/F and general-purpose
magnetic flux, only the secondary functions are selected.
4. Pr. 180 to Pr. 183 (input terminal (remote output) function selection) do not
function if the values set are other than the above.
4
