APPENDIX 1 Data Code List
171
APPENDIX
APPENDIX 1 Data Code List
Data Code
Func-
tion
Parameter
Number
Name
Read Write
Link Parameter Extension
Setting
(Data Code 7F/FF)
0
Torque boost
00 80 0
1
Maximum frequency
01 81 0
2
Minimum frequency
02 82 0
3
Base frequency
03 83 0
4
Multi-speed setting (high speed)
04 84 0
5
Multi-speed setting (middle speed)
05 85 0
6
Multi-speed setting (low speed)
06 86 0
7
Acceleration time
07 87 0
8
Deceleration time
08 88 0
Basic functions
9
Electronic thermal O/L relay
09 89 0
10
DC injection brake operation
frequency
0A 8A 0
11
DC injection brake operation time
0B 8B 0
12
DC injection brake voltage
0C 8C 0
13
Starting frequency
0D 8D 0
14
Load pattern selection
0E 8E 0
18
High-speed maximum frequency
12 92 0
19
Base frequency voltage
13 93 0
20
Acceleration/deceleration
reference frequency
14 94 0
21
Acceleration/deceleration time
increments
15 95 0
22
Stall prevention operation level
16 96 0
23
Stall prevention operation level
compensation factor at double
speed
17 97 0
24
Multi-speed setting (speed 4)
18 98 0
25
Multi-speed setting (speed 5)
19 99 0
26
Multi-speed setting (speed 6)
1A 9A 0
27
Multi-speed setting (speed 7)
1B 9B 0
29
Acceleration/deceleration pattern
1D 9D 0
30
Regenerative function selection
1E 9E 0
31
Frequency jump 1A
1F 9F 0
32
Frequency jump 1B
20 A0 0
33
Frequency jump 2A
21 A1 0
34
Frequency jump 2B
22 A2 0
35
Frequency jump 3A
23 A3 0
36
Frequency jump 3B
24 A4 0
Standard operation functions
37
Speed display
25 A5 0
41
Up-to-frequency sensitivity 29 A9
0
42
Output frequency detection
2A AA 0
Output
terminal
functions
43
Output frequency detection for
reverse rotation
2B AB 0
44
Second acceleration/deceleration
time
2C AC 0
45
Second deceleration time
2D AD 0
46
Second torque boost
2E AE 0
47
Second V/F (base frequency)
2F AF 0
Second functions
48
Second electronic overcurrent
protection
30 B0 0
Display
functions
52
PU main display data selection
34 B4 0
