2.2.4 Wiring of CC-Link communication signals
(
1
)
Terminal block wiring
The terminals for CC-Link communication signals are arranged in the inverter as
shown below.
Terminal screw size: M2.5
DA
DB
DG
SLD
SLD
FG
(2) Wiring of inverter and PLC
UR (L
1
)
VS (L
2
)
WT (L
3
)
DADADA
DBDB
DGDG
SLDSLD
FG
PLC CC-Link
master module
Power
supply
Inverter
Motor
