PARAMETERS
75
4.1.3 Parameters recommended to be set by the user
We recommend the following parameters to be set by the user.
Set them according to the operation specifications, load, etc.
Parameter
Number
Name Application
1 Maximum frequency
2 Minimum frequency
Used to set the maximum and minimum output
frequencies.
7 Acceleration time
8 Deceleration time
Used to set the acceleration and deceleration
times.
9
Electronic overcurrent
protection
Used to set the current of the electronic
overcurrent protection to protect the motor from
overheat.
14
Load pattern
selection
Used to select the optimum output characteristics
which match the application and load
characteristics.
71 Applied motor
Used to set the thermal characteristics of the
electronic overcurrent protection according to the
motor used.
4
