INSTALLATION AND WIRING
14
(
3
)
CC-Link communication signals
Terminal Symbol Terminal Name Description
DA
DB
DG
SLD
SLD
FG
CC-Link
communication
signals
Connected with the master station and other local stations to make
CC-Link communication.
(
4
)
RS-485 communication
Name Description
PU connector
Communication can be made by the PU connector in accordance with RS-485.
!
Compliant standard: EIA Standard RS-485
!
Transmission form: Multidrop link system
!
Communication speed: Max. 19200 baud
!
Overall distance: 500m
