INSTALLATION AND WIRING
46
3) Outline of instructions
* Connect the equipment to the earth securely. Do not use an earth leakage
circuit breaker as an electric shock protector without connecting the
equipment to the earth.
* Wire the earth terminal independently. (Do not connect two or more cables to
one terminal.)
* The wire size on pages 16 and 17 are shown for following conditions
"
Ambient Temp : 40
°
C maximum
"
Wire installation : On wall without ducts or conduits
If conditions are different from above, select appropriate wire according to
EN60204 ANNEX C TABLE 5.
* Use the no-fuse breaker and magnetic contactor which conform to the EN or
IEC Standard.
Design notice: Where residual-current-operated protective device (RCD) is
used for protection in case of direct or indirect contact, only
RCD of Type B is allowed on the supply side of this
Electronic Equipment (EE). Otherwise another protective
measure shall be applied such as separation of the EE from
the environment by double or reinforced insulation or
isolation of EE and supply system by a transformer. (Extract
from EN51078)
* Use the inverter under the conditions of overvoltage category II and
contamination level 2 or higher specified in IEC664.
* On the input and output of the inverter, use cables of the type and size set
forth in EN60204 Appendix C.
* The operating capacity of the relay outputs (terminal symbols A, B, C) should
be 30VDC, 0.3A.
* The terminals indicated as the input and output terminals for control circuit on
page 12 are isolated safely from the main circuit.
Environment
During
operation
In storage
During
transportation
Ambient
Temperature
-10
°
C to
+
50
°
C-20
°
C to
+
65
°
C-20
°
C to
+
65
°
C
Ambient Humidity 90% RH or less 90% RH or less 90% RH or less
Maximum Altitude 1,000 m 1,000 m 10,000 m
Details are given in the technical information "Low Voltage Directive
Conformance Guide" (BCN-A21041-203). Please contact your sales
representative.
