Mitsubishi FREQROL-E700 User Manual

App.1-2
Parameter Name Setting range Initial value
51
Second electronic
thermal O/L relay
0 to 500 A,
9999
9999
52
DU/PU main display
data selection
0, 5, 7 to 12,
14, 20, 23 to
25, 52 to 57,
61, 62, 100
0
54
FM terminal function
selection
1 to 3, 5,
7 to 12, 14,
21 ,24, 52,
53, 61, 62
1
55
Frequency monitor
reference
0 to 400Hz 60Hz
56
Current monitoring
reference
0 to 500A
Inverter
rated
current
57
Restart coasting
time
0, 0.1 to 5s,
9999
9999
58 Restart cushion time 0 to 60s 1s
59
Remote function
selection
0, 1, 2, 3 0
60
Energy saving
control selection
0, 9 0
61 Reference current
0 to 500A,
9999
9999
62
Reference value at
acceleration
0 to 200%,
9999
9999
63
Reference value at
deceleration
0 to 200%,
9999
9999
65 Retry selection 0 to 5 0
66
Stall prevention
operation reduction
starting frequency
0 to 400Hz 60Hz
67
Number of retries at
fault occurrence
0 to 10,
101 to 110
0
68 Retry waiting time 0.1 to 360s 1s
69
Retry count display
erase
0 0
70
Special regenerative
brake duty
0 to 30% 0%
71 Applied motor
0, 1, 3 to 6, 13
to 16, 23, 24,
40, 43, 44, 50,
53, 54
0
72
PWM frequency
selection
0 to 15 1
73
Analog input
selection
0, 1, 10, 11 1
74
Input lter time
constant
0 to 8 1
75
Reset selection/
disconnected PU
detection/PU stop
selection
0 to 3, 14 to 17 14
Parameter Name Setting range Initial value
77
Parameter write
selection
0, 1, 2 0
78
Reverse rotation
prevention selection
0, 1, 2 0
79
Operation mode
selection
0, 1, 2, 3, 4,
6, 7
0
80 Motor capacity
0.1 to 15kW,
9999
9999
81
Number of motor
poles
2, 4, 6, 8, 10,
9999
9999
82
Motor excitation
current
0 to 500A
(0 to ****),
9999
*5
9999
83 Rated motor voltage 0 to 1000V 200/400V
*4
84
Rated motor
frequency
10 to 120Hz 60Hz
89
Speed control gain
(Advanced magnetic
ux vector)
0 to 200%,
9999
9999
90 Motor constant (R1)
0 to 50Ω
(0 to ****),
9999
*5
9999
91 Motor constant (R2)
0 to 50Ω
(0 to ****),
9999
*5
9999
92 Motor constant (L1)
0 to 1000mH
(0 to 50Ω,
0 to ****),
9999
*5
9999
93 Motor constant (L2)
0 to 1000mH
(0 to 50Ω,
0 to ****),
9999
*5
9999
94 Motor constant (X)
0 to 100%
(0 to 500Ω,
0 to ****),
9999
*5
9999
96
Auto tuning setting/
status
0, 1, 11, 21 0
117
PU communication
station number
0 to 31
(0 to 247)
0
118
PU communication
speed
48, 96, 192,
384
192
119
PU communication
stop bit length
0, 1, 10, 11 1
120
PU communication
parity check
0, 1, 2 2
121
Number of PU
communication
retries
0 to 10, 9999 1
122
PU communication
check time interval
0.01 to 999.8s,
9999
0
123
PU communication
waiting time setting
0 to 150ms,
9999
9999
