Parameter Name Setting range Initial value
124
PU communication
CR/LF selection
0, 1, 2 1
125
Terminal 2
frequency setting
gain frequency
0 to 400Hz 60Hz
126
Terminal 4
frequency setting
gain frequency
0 to 400Hz 60Hz
127
PID control
automatic
switchover
frequency
0 to 400Hz,
9999
9999
128 PID action selection
0, 20, 21,
40 to 43, 50,
51, 60, 61
0
129
PID proportional
band
0.1 to 1000%,
9999
100%
130 PID integral time
0.1 to 3600s,
9999
1s
131 PID upper limit
0 to 100%,
9999
9999
132 PID lower limit
0 to 100%,
9999
9999
133 PID action set point
0 to 100%,
9999
9999
134 PID differential time
0.01 to 10.00s
9999
9999
145
PU display language
selection
0 to 7 0
146
*6
Built-in
potentiometer
switching
0, 1 1
147
Acceleration/
deceleration time
switching frequency
0 to 400Hz,
9999
9999
150
Output current
detection level
0 to 200% 150%
151
Output current
detection signal
delay time
0 to 10s 0s
152
Zero current
detection level
0 to 200% 5%
153
Zero current
detection time
0 to 1s 0.5s
156
Stall prevention
operation selection
0 to 31, 100,
101
0
157
OL signal output
timer
0 to 25s, 9999 0s
160
User group read
selection
0, 1, 9999 0
161
Frequency setting/
key lock operation
selection
0, 1, 10, 11 0
Parameter Name Setting range Initial value
162
Automatic restart
after instantaneous
power failure
selection
0, 1, 10, 11 1
165
Stall prevention
operation level for
restart
0 to 200% 150%
168
Parameter for manufacturer setting. Do not set.
169
170
Watt-hour meter
clear
0, 10, 9999 9999
171
Operation hour
meter clear
0, 9999 9999
172
User group
registered display/
batch clear
9999, (0 to 16) 0
173
User group
registration
0 to 999, 9999 9999
174 User group clear 0 to 999, 9999 9999
178
STF terminal
function selection
0 to 5, 7, 8,
10, 12, 14 to
16, 18, 24, 25,
60 (Pr. 178),
61 (Pr. 179),
62, 65 to 67,
9999
60
179
STR terminal
function selection
61
180
RL terminal function
selection
0
181
RM terminal function
selection
1
182
RH terminal function
selection
2
183
MRS terminal
function selection
24
184
RES terminal
function selection
62
190
RUN terminal
function selection
0, 1, 3, 4, 7, 8,
11 to 16, 20,
25, 26, 46, 47,
64, 90, 91, 93
(Pr. 190, Pr.
191), 95, 96,
98, 99, 100,
101, 103,
104, 107, 108,
111 to 116,
120, 125, 126,
146, 147, 164,
190, 191, 193
(Pr. 190, Pr.
191), 195,
196, 198, 199,
9999
0
191
FU terminal function
selection
4
192
A, B, C terminal
function selection
99
232
Multi-speed setting
(8 levels of speed)
0 to 400Hz,
9999
9999
233
Multi-speed setting
(9 levels of speed)
0 to 400Hz,
9999
9999
