Mitsubishi FREQROL-E700

App.1-4
Parameter Name Setting range Initial value
234
Multi-speed setting
(10 levels of speed)
0 to 400Hz,
9999
9999
235
Multi-speed setting
(11 levels of speed)
0 to 400Hz,
9999
9999
236
Multi-speed setting
(12 levels of speed)
0 to 400Hz,
9999
9999
237
Multi-speed setting
(13 levels of speed)
0 to 400Hz,
9999
9999
238
Multi-speed setting
(14 levels of speed)
0 to 400Hz,
9999
9999
239
Multi-speed setting
(15 levels of speed)
0 to 400Hz,
9999
9999
240
Soft-PWM operation
selection
0, 1 1
241
Analog input display
unit switchover
0, 1 0
244
Cooling fan
operation selection
0, 1 1
245 Rated slip
0 to 50%,
9999
9999
246
Slip compensation
time constant
0.01 to 10s 0.5s
247
Constant-power
range slip
compensation
selection
0, 9999 9999
249
Earth (ground) fault
detection at start
0, 1 0
250 Stop selection
0 to 100s,
1000 to 1100s
8888, 9999
9999
251
Output phase loss
protection selection
0, 1 1
255
Life alarm status
display
(0 to 15) 0
256
Inrush current limit
circuit life display
(0 to 100%) 100%
257
Control circuit
capacitor life display
(0 to 100%) 100%
258
Main circuit
capacitor life display
(0 to 100%) 100%
259
Main circuit
capacitor life
measuring
0, 1 (2, 3, 8, 9) 0
261
Power failure stop
selection
0, 1, 2 0
267
Terminal 4 input
selection
0, 1, 2 0
268
Monitor decimal
digits selection
0, 1, 9999 9999
269 Parameter for manufacturer setting. Do not set.
270
Stop-on contact
control selection
0, 1 0
Parameter Name Setting range Initial value
275
Stop-on contact
excitation current
low-speed
multiplying factor
0 to 300%,
9999
9999
276
PWM carrier
frequency at stop-on
contact
0 to 9, 9999 9999
277
Stall prevention
operation current
switchover
0, 1 0
278
Brake opening
frequency
0 to 30Hz 3Hz
279
Brake opening
current
0 to 200% 130%
280
Brake opening
current detection
time
0 to 2s 0.3s
281
Brake operation
time at start
0 to 5s 0.3s
282
Brake operation
frequency
0 to 30Hz 6Hz
283
Brake operation
time at stop
0 to 5s 0.3s
286 Droop gain 0 to 100% 0%
287
Droop lter time
constant
0 to 1s 0.3s
292
Automatic
acceleration/
deceleration
0, 1, 7, 8, 11 0
293
Acceleration/
deceleration
separate selection
0 to 2 0
295
Magnitude of
frequency change
setting
0, 0.01, 0.1
1, 10
0
296 Password lock level
0 to 6, 99, 100
to 106, 199,
9999
9999
297
Password lock/
unlock
(0 to 5),
1000 to 9998,
9999
9999
298
Frequency search
gain
0 to 32767,
9999
9999
299
Rotation direction
detection selection
at restarting
0, 1, 9999 0
338
Communication
operation command
source
0, 1 0
339
Communication
speed command
source
0, 1, 2 0
340
Communication
startup mode
selection
0, 1, 10 0
