13-17
6. Remove the screw at the bottom of the
dummy lamp , then remove the lamp toward
the outside of the vehicle.
7. Remove the headlamp’s bolts and connectors
.
CAUTION
• Do not turn the beam adjusting screw .
Turning the beam adjusting screw would
change the beam setting, thus creating a
nuisance for drivers of other vehicles. If you
accidentally turn the beam adjusting screw,
have an authorized dealer perform neces-
sary inspection.
• When setting down the removed headlamp,
place it on a soft cloth to avoid scratching
the lens.
8. Raise the headlamp slightly to remove the tabs
from the holes , then pull it out toward you.
Z11268
Z11269
Z11270
Z11271
