FX3G/FX3U/FX3GC/FX3UC Series
Programming Manual - Basic & Applied Instruction Edition
3 Instruction List
3.3 Applied Instructions ... in Ascending Order of FNC Number
1
Introduction
2
Overview
3
Instruction List
4
Devices in Detail
5
Specified the Device & Constant
6
Before Programming
7
Basic Instruction
8
FNC00-FNC09 Program Flow
9
FNC10-FNC19 Move & Compare
10
FNC20-FNC29 Arith. & Logic Operation
Floating Point
128 ENEG Floating Point Negation – – 33–––––
Section
18.16
129 INT
Floating Point to Integer
Conversion
*6 333 ––3 – 3
Section
18.17
130 SIN Floating Point Sine – – 33 ––3 – 3
Section
18.18
131 COS Floating Point Cosine – – 33 ––3 – 3
Section
18.19
132 TAN Floating Point Tangent – – 33––3 – 3
Section
18.20
133 ASIN Floating Point Arc Sine – – 33 –––––
Section
18.21
134 ACOS Floating Point Arc Cosine – – 33 –––––
Section
18.22
135 ATAN Floating Point Arc Tangent – – 33 –––– –
Section
18.23
136 RAD
Floating Point Degrees to
Radians Conversion
––33 –––––
Section
18.24
137 DEG
Floating Point Radians to
Degrees Conversion
––33 –––––
Section
18.25
138,
139
– –
Data Operation 2
140 WSUM Sum of Word Data – – 3 *5 – – – – –
Section
19.1
141 WTOB WORD to BYTE – – 3 *5 – – – – –
Section
19.2
142 BTOW BYTE to WORD – – 3 *5 – – – – –
Section
19.3
143 UNI 4-bit Linking of Word Data – – 3 *5 – – – – –
Section
19.4
144 DIS
4-bit Grouping of Word
Data
––3 *5 – – – – –
Section
19.5
145,
146
– –
147 SWAP Byte Swap – – 33 ––3 – 3
Section
19.6
148 – –
149 SORT2 Sort Tabulated Data 2 – – 3 *5 – – – – –
Section
19.7
*1: The instruction is provided in the FX 2N /FX 2NC Series Ver. 3.00 or later. *6: The instruction is provided in the FX 3G Series Ver. 1.10 or later.
*2: The function is changed in the FX 3UC Series Ver. 1.30 or later. *7: The instruction is provided in the FX 3U /FX 3UC Series Ver. 2.61 or later.
*3: The instruction is provided in the FX
3UC Series Ver. 1.30 or later. *8: The instruction is provided in the FX 3U /FX 3UC Series Ver. 2.70 or later.
*4: The function is changed in the FX
3UC Series Ver. 2.20 or later. *9: The instruction is provided in the FX 3G Series Ver. 1.40 or later.
*5: The instruction is provided in the FX 3UC Series Ver. 2.20 or later.
FNC No. Mnemonic Symbol Function
FX3G
FX3GC
FX3U
FX3UC
Applicable PLC
Reference
FX1S
FX1N FX2N
FX1NC FX2NC
DENEG
DSINT
DSSIN
DSCOS
DSTAN
DSASIN
DSACOS
DSATAN
DSRAD
DSDEG
WSUM nDS
WTOB nDS
BTOW nDS
UNI nDS
DIS nDS
S
SWAP
SORT2 nm2m1S D

Mitsubishi FX3G Series Specifications

General

Model	FX3G Series
Power Supply	AC 100-240V or DC 24V
Program Capacity	32, 000 steps
Execution Speed	0.21 µs/basic instruction
Communication Options	RS-422, USB, Ethernet
Expansion Modules	Analog, digital, communication
Programming Language	Ladder Logic, Instruction List
Built-in Functions	High-speed counters, pulse output
Analog I/O	Available via expansion modules
